Saturday, 30 March 2013



VBA Macro To Convert PDF Files Into Different Format

A couple of days ago, Peter asked me on this post if it is possible to save a PDF file as an Excel table by using VBA. I started thinking his question and I thought that it could be quite useful if I can automate the procedure of saving a PDF file into other format. The procedure that I wrote requires Adobe Professional in order to work. So, if you have installed Adobe Professional at your computer and you need to convert some PDF files into Word files for example, take a look at the code below.

Apart from the main procedure I also wrote a loop in order to convert multiple PDF files at once. So, if you have a folder that contains PDF files you can use this tool to obtain their file paths. Then you can use the attached workbook in order to convert them to a different format. The code actually uses the Save As command of the Adobe Professional in order to save the files to the desired format. The available formats are:
  • eps
  • html and htm
  • jpeg, jpg and jpe
  • jpf, jpx, jp2, j2k, j2c and jpc
  • docx
  • doc
  • png
  • ps
  • rft
  • xlsx
  • xls
  • txt
  • tiff and tif
  • xml


VBA code

Option Explicit
Option Private Module

Sub SavePDFAsOtherFormat(PDFPath As String, FileExtension As String)

    'Saves a PDF file as another format using Adobe Professional.

    'By Christos Samaras
    'http://www.myengineeringworld.net

    'In order to use the macro you must enable the Acrobat library from VBA editor:
    'Go to Tools -> References -> Adobe Acrobat xx.0 Type Library, where xx depends
    'on your Acrobat Professional version (i.e. 9.0 or 10.0) you have installed to your PC.

    'Alternatively you can find it Tools -> References -> Browse and check for the path
    'C:\Program Files\Adobe\Acrobat xx.0\Acrobat\acrobat.tlb
    'where xx is your Acrobat version (i.e. 9.0 or 10.0 etc.).

    Dim objAcroApp      As Acrobat.AcroApp
    Dim objAcroAVDoc    As Acrobat.AcroAVDoc
    Dim objAcroPDDoc    As Acrobat.AcroPDDoc
    Dim objJSO          As Object
    Dim boResult        As Boolean
    Dim ExportFormat    As String
    Dim NewFilePath     As String

    'Check if the file exists.
    If Dir(PDFPath) = "" Then
        MsgBox "Cannot find the PDF file!" & vbCrLf & "Check the PDF path and retry.", _
                vbCritical, "File Path Error"
        Exit Sub
    End If

    'Check if the input file is a PDF file.
    If LCase(Right(PDFPath, 3)) <> "pdf" Then
        MsgBox "The input file is not a PDF file!", vbCritical, "File Type Error"
        Exit Sub
    End If

    'Initialize Acrobat by creating App object.
    Set objAcroApp = CreateObject("AcroExch.App")

    'Set AVDoc object.
    Set objAcroAVDoc = CreateObject("AcroExch.AVDoc")

    'Open the PDF file.
    boResult = objAcroAVDoc.Open(PDFPath, "")

    'Set the PDDoc object.
    Set objAcroPDDoc = objAcroAVDoc.GetPDDoc

    'Set the JS Object - Java Script Object.
    Set objJSO = objAcroPDDoc.GetJSObject

    'Check the type of conversion.
    Select Case LCase(FileExtension)
        Case "eps": ExportFormat = "com.adobe.acrobat.eps"
        Case "html", "htm": ExportFormat = "com.adobe.acrobat.html"
        Case "jpeg", "jpg", "jpe": ExportFormat = "com.adobe.acrobat.jpeg"
        Case "jpf", "jpx", "jp2", "j2k", "j2c", "jpc": ExportFormat = "com.adobe.acrobat.jp2k"
        Case "docx": ExportFormat = "com.adobe.acrobat.docx"
        Case "doc": ExportFormat = "com.adobe.acrobat.doc"
        Case "png": ExportFormat = "com.adobe.acrobat.png"
        Case "ps": ExportFormat = "com.adobe.acrobat.ps"
        Case "rft": ExportFormat = "com.adobe.acrobat.rft"
        Case "xlsx": ExportFormat = "com.adobe.acrobat.xlsx"
        Case "xls": ExportFormat = "com.adobe.acrobat.spreadsheet"
        Case "txt": ExportFormat = "com.adobe.acrobat.accesstext"
        Case "tiff", "tif": ExportFormat = "com.adobe.acrobat.tiff"
        Case "xml": ExportFormat = "com.adobe.acrobat.xml-1-00"
        Case Else: ExportFormat = "Wrong Input"
    End Select

    'Check if the format is correct and there are no errors.
    If ExportFormat <> "Wrong Input" And Err.Number = 0 Then

        'Format is correct and no errors.

        'Set the path of the new file. Note that Adobe instead of xls uses xml files.
        'That's why here the xls extension changes to xml.
        If LCase(FileExtension) <> "xls" Then
            NewFilePath = WorksheetFunction.Substitute(PDFPath, ".pdf", "." & LCase(FileExtension))
        Else
            NewFilePath = WorksheetFunction.Substitute(PDFPath, ".pdf", ".xml")
        End If

        'Save PDF file to the new format.
        boResult = objJSO.SaveAs(NewFilePath, ExportFormat)

        'Close the PDF file without saving the changes.
        boResult = objAcroAVDoc.Close(True)

        'Close the Acrobat application.
        boResult = objAcroApp.Exit

        'Inform the user that conversion was successfully.
        MsgBox "The PDf file:" & vbNewLine & PDFPath & vbNewLine & vbNewLine & _
        "Was saved as: " & vbNewLine & NewFilePath, vbInformation, "Conversion finished successfully"

    Else

        'Something went wrong, so close the PDF file and the application.

        'Close the PDF file without saving the changes.
        boResult = objAcroAVDoc.Close(True)

        'Close the Acrobat application.
        boResult = objAcroApp.Exit

        'Inform the user that something went wrong.
        MsgBox "Something went wrong!" & vbNewLine & "The conversion of the following PDF file FAILED:" & _
        vbNewLine & PDFPath, vbInformation, "Conversion failed"

    End If

    'Release the objects.
    Set objAcroPDDoc = Nothing
    Set objAcroAVDoc = Nothing
    Set objAcroApp = Nothing

End Sub

Here is the macro that loops through all the file paths that are contained in column "B" of the sheet "Paths" and converts the PDF files into a different file type. The macro ExportAllPDFs uses the SavePDFAsOtherFormatNoMsg macro, which is similar to SavePDFAsOtherFormat macro, but, without the message boxes.

Sub ExportAllPDFs()

    'Convert all the PDF files that their paths are on column B of
    'the worksheet "Paths" into a different file format.
    'By Christos Samaras
    'http://www.myengineeringworld.net

    Dim FileFormat As String
    Dim LastRow As Long
    Dim i As Integer

    'Change this according to your own needs.
    'Available formats: eps html, htm jpeg, jpg, jpe jpf, jpx, jp2,
    'j2k, j2c, jpc, docx, doc, png, ps, rft, xlsx, xls, txt, tiff, tif and xml.
    'In this example the PDF file will be saved as text file.
    FileFormat = "txt"

    If FileFormat = "" Then
        shPaths.Range("B2").Select
        MsgBox "There are no file paths to convert!", vbInformation, "File paths missing"
        Exit Sub
    End If

    shPaths.Activate

    'Find the last row.
    With shPaths
        LastRow = .Cells(.Rows.Count, "B").End(xlUp).Row
    End With

    'Check that there are available file paths.
    If LastRow < 2 Then
        shPaths.Range("B2").Select
        MsgBox "There are no file paths to convert!", vbInformation, "File paths missing"
        Exit Sub
    End If

    'For each cell in the range "B2:B" & last row convert the pdf file
    'into different format (here to text - txt).
    For i = 2 To LastRow
        SavePDFAsOtherFormatNoMsg Cells(i, 2).Value, FileFormat
    Next i

    'Inform the user that conversion finished.
    MsgBox "All files were converted successfully!", vbInformation, "Finished"

End Sub


Download it from here


The file can be opened with Excel 2007 or newer. Please, remember to enable macros before using it.


Update

Update 18/7/2013

I saw that the previous workbook was not so convenient for converting multiple PDF files, so I decided to change a little bit the two macros. You can find the new VBA code below, as well as the new workbook in the download section that follows.

Option Explicit
Option Private Module

Sub ExportAllPDFs()

    '----------------------------------------------------------------
    'Converts all the PDF files that their paths are in column A of
    'the worksheet "Convert PDF Files" into a different file format,
    'based on the value in column B (extension).

    'By Christos Samaras
    'Date: 18/07/2013
    'http://www.myengineeringworld.net
    '----------------------------------------------------------------

    Dim LastRow As Long
    Dim i As Integer

    shPaths.Activate

    'Find the last row.
    With shPaths
        LastRow = .Cells(.Rows.Count, "A").End(xlUp).Row
    End With

    'Check that there are available file paths.
    If LastRow < 2 Then
        shPaths.Range("A2").Select
        MsgBox "There are no file paths to convert!", vbInformation, "File paths missing"
        Exit Sub
    End If

    'Checking for errors before conversion.
    For i = 2 To LastRow

        'Check if the file extensions are not empty.
        If Cells(i, 2).Value = "" Then
            shPaths.Cells(i, 2).Select
            MsgBox "Please select an output format from the dropdown list!", vbCritical, "File paths missing"
            Exit Sub
        End If

        'Check if the file exists.
        If Dir(shPaths.Cells(i, 1).Value) = "" Then
            shPaths.Cells(i, 1).Select
            MsgBox "The file path is not valid!", vbCritical, "File path error"
            Exit Sub
        End If

        'Check if the input file is a PDF file.
        If LCase(Right(shPaths.Cells(i, 1).Value, 3)) <> "pdf" Then
            shPaths.Cells(i, 1).Select
            MsgBox "The file is not a pdf file!", vbCritical, "No pdf file"
            Exit Sub
        End If

    Next i

    'For each cell in the range "A2:A" & last row convert the pdf file
    'into different format according to the "B2:B" & last row value.
    For i = 2 To LastRow
        SavePDFAs Cells(i, 1).Value, Cells(i, 2).Value
    Next i

    'Adjust the two columns.
    Columns("A:B").EntireColumn.AutoFit

    'Inform the user that conversion finished.
    MsgBox "All files were converted successfully!", vbInformation, "Finished"

End Sub

Private Sub SavePDFAs(PDFPath As String, FileExtension As String)

    '---------------------------------------------------------------------------------------
    'Saves a PDF file as other format using Adobe Professional.

    'In order to use the macro you must enable the Acrobat library from VBA editor:
    'Go to Tools -> References -> Adobe Acrobat xx.0 Type Library, where xx depends
    'on your Acrobat Professional version (i.e. 9.0 or 10.0) you have installed to your PC.

    'Alternatively you can find it Tools -> References -> Browse and check for the path
    'C:\Program Files\Adobe\Acrobat xx.0\Acrobat\acrobat.tlb
    'where xx is your Acrobat version (i.e. 9.0 or 10.0 etc.).

    'By Christos Samaras
    'Date: 30/03/2013
    'http://www.myengineeringworld.net
    '---------------------------------------------------------------------------------------

    Dim objAcroApp      As Acrobat.AcroApp
    Dim objAcroAVDoc    As Acrobat.AcroAVDoc
    Dim objAcroPDDoc    As Acrobat.AcroPDDoc
    Dim objJSO          As Object
    Dim boResult        As Boolean
    Dim ExportFormat    As String
    Dim NewFilePath     As String

    'Initialize Acrobat by creating App object.
    Set objAcroApp = CreateObject("AcroExch.App")

    'Set AVDoc object.
    Set objAcroAVDoc = CreateObject("AcroExch.AVDoc")

    'Open the PDF file.
    boResult = objAcroAVDoc.Open(PDFPath, "")

    'Set the PDDoc object.
    Set objAcroPDDoc = objAcroAVDoc.GetPDDoc

    'Set the JS Object - Java Script Object.
    Set objJSO = objAcroPDDoc.GetJSObject

    'Check the type of conversion.
    Select Case LCase(FileExtension)
        Case "eps": ExportFormat = "com.adobe.acrobat.eps"
        Case "html", "htm": ExportFormat = "com.adobe.acrobat.html"
        Case "jpeg", "jpg", "jpe": ExportFormat = "com.adobe.acrobat.jpeg"
        Case "jpf", "jpx", "jp2", "j2k", "j2c", "jpc": ExportFormat = "com.adobe.acrobat.jp2k"
        Case "docx": ExportFormat = "com.adobe.acrobat.docx"
        Case "doc": ExportFormat = "com.adobe.acrobat.doc"
        Case "png": ExportFormat = "com.adobe.acrobat.png"
        Case "ps": ExportFormat = "com.adobe.acrobat.ps"
        Case "rft": ExportFormat = "com.adobe.acrobat.rft"
        Case "xlsx": ExportFormat = "com.adobe.acrobat.xlsx"
        Case "xls": ExportFormat = "com.adobe.acrobat.spreadsheet"
        Case "txt": ExportFormat = "com.adobe.acrobat.accesstext"
        Case "tiff", "tif": ExportFormat = "com.adobe.acrobat.tiff"
        Case "xml": ExportFormat = "com.adobe.acrobat.xml-1-00"
        Case Else: ExportFormat = "Wrong Input"
    End Select

    'Check if the format is correct and there are no errors.
    If ExportFormat <> "Wrong Input" And Err.Number = 0 Then

        'Format is correct and no errors.

        'Set the path of the new file. Note that Adobe instead of xls uses xml files.
        'That's why here the xls extension changes to xml.
        If LCase(FileExtension) <> "xls" Then
            NewFilePath = WorksheetFunction.Substitute(PDFPath, ".pdf", "." & LCase(FileExtension))
        Else
            NewFilePath = WorksheetFunction.Substitute(PDFPath, ".pdf", ".xml")
        End If

        'Save PDF file to the new format.
        boResult = objJSO.SaveAs(NewFilePath, ExportFormat)

        'Close the PDF file without saving the changes.
        boResult = objAcroAVDoc.Close(True)

        'Close the Acrobat application.
        boResult = objAcroApp.Exit

    Else

        'Something went wrong, so close the PDF file and the application.

        'Close the PDF file without saving the changes.
        boResult = objAcroAVDoc.Close(True)

        'Close the Acrobat application.
        boResult = objAcroApp.Exit

    End If

    'Release the objects.
    Set objAcroPDDoc = Nothing
    Set objAcroAVDoc = Nothing
    Set objAcroApp = Nothing

End Sub


Video

You can watch the VBA code in action on this short video:



Download it from here


The new file can be opened with Excel 2007 or newer. Please, remember that you will need Adobe Professional for the conversion. The code will NOT work with Adobe Reader.


Read also

VBA Macro To Open A PDF File
Open PDF File With VBA
Export Excel Charts As TIFF images Using Adobe Professional

Did you like this post? If yes, then share it with your friends. Thank you!



Categories:


Mechanical Engineer (Ph.D. cand.), M.Sc. Cranfield University, Dipl.-Ing. Aristotle University, Thessaloniki - Greece.
Communication: tel. +30-6973513308, e-mail , Facebook , Twitter , Google+ and Linkedin . Full CV
